Product Introduction
This sky jack self propelled scissor lift features an X-shaped scissor mechanism, ensuring smooth and steady lifting without any wobbling. Constructed from high-strength steel, the unit is further equipped with an automatic hydraulic leveling system, a non-slip platform, and adjustable guardrails to enhance operational safety. Suitable for a wide range of applications including interior decoration, warehouse shelving organization, and equipment maintenance,it offers simple operation, flexible maneuverability, and exceptional stability.
Product Parameters
|
Model |
HLPT-1214 |
Wheelbase |
1.92m |
|
Safe working load |
320kg |
Minimum turning radius (inner wheel) |
0 |
|
Extended platform SWL |
100kg |
Minimum turning radius (outer wheel) |
2.35m |
|
Maximum working height (A) |
14m |
Lifting motor/driving motor |
24v/4.5kw |
|
Maximum platform height (B) |
12m |
Machine travel speed (retraction state) |
3.5km/h |
|
Overall length (C) |
2.46m |
Driving speed of machine (lifting status) |
0.8km/h |
|
Width of complete machine (D) |
1.18m |
Rise/Fall Speed |
4-6m/min |
|
Overall height (fence not folded) |
2.60m |
storage battery |
4*6V200Ah |
|
Overall height (fence folding) (E) |
2.09m |
charger |
24v/30A |
|
Platform dimensions (length x width (F)) |
2.3m*1.14m |
Max Climb Capability |
25% |
|
Platform extension size (G) |
0.9m |
Maximum allowable working angle (indoor/outdoor) |
3° |
|
Minimum ground clearance (retraction state) |
0.1m |
Tyre |
Φ381*127mm |
|
Minimum ground clearance (lifting status) |
0.02m |
Weight of complete machine |
2950kg |
Product Details
Product features
1.Featuring a compact and robust structure, this unit is safe and reliable, capable of withstanding even daily, high-frequency usage without issue.
2.The lifting mechanism is stable and precise, effortlessly raising heavy-tonnage loads. Its hydraulic system incorporates anti-jamming and overload protection features, ensuring safe operation.
3.The lifting process is smooth and vibration free; thanks to its compact body, the unit is highly convenient for both daily use and routine maintenance.
4.It boasts a strong load-bearing capacity, delivers high operational efficiency, and operates with minimal noise.
5.A wide range of compatible accessories is available to meet the specific requirements of various application scenarios.
Product Application
Company Profile
Our Advantages
- Comprehensive Control: As a manufacturer operating our own factory, we strictly oversee every stage of production to ensure that the quality of every electric scissor lift meets our rigorous standards.
- Flexible Customization: We support on-demand customization, allowing you to select specific heights, colors, and features; we can develop a tailored solution designed specifically for your operational environment.
- Rapid Response: Orders and customization requests are processed directly at our facility, ensuring quick response times, short lead times, and superior efficiency.
- Technical Support: A professional technical team provides end-to-end support from initial consultation through to after sales maintenance ensuring you receive reliable assistance at every step.
- Quality Assurance: Every unit undergoes rigorous testing before leaving our factory to guarantee stable and reliable performance, giving our users complete peace of mind.
