Product Introduction
The electric self-propelled scissor lift is an aerial work platform capable of both vertical lifting and independent movement. Stable, agile, and highly safe, it is particularly well-suited for use in environments such as factories, construction sites, and logistics warehouses. Featuring a high-strength scissor mechanism paired with an electric drive system, the equipment can maneuver autonomously and position itself with precision; this ensures high operational efficiency while significantly reducing labor costs.
Product Parameters
|
Model |
HLPT-1820 |
Wheelbase |
3.8m |
|
Safe working load |
300kg |
Minimum turning radius (inner wheel) |
0 |
|
Extended platform SWL |
100kg |
Minimum turning radius (outer wheel) |
3.9m |
|
Maximum working height (A) |
20m |
Lifting motor/driving motor |
48v/4kw |
|
Maximum platform height (B) |
18m |
Machine travel speed (retraction state) |
3.5km/h |
|
Overall length (C) |
3.96m |
Driving speed of machine (lifting status) |
0.8km/h |
|
Width of complete machine (D) |
1.87m |
Rise/Fall Speed |
4-6m/min |
|
Overall height (fence not folded) |
2.95m |
storage battery |
8*12V/150Ah |
|
Overall height (fence folding) (E) |
2.35m |
charger |
24v/30A |
|
Platform dimensions (length x width (F)) |
3m*1.5m |
Max Climb Capability |
25% |
|
Platform extension size (G) |
0.9m |
Maximum allowable working angle (indoor/outdoor) |
3° |
|
Minimum ground clearance (retraction state) |
0.1m |
Tyre |
Φ400*127mm |
|
Minimum ground clearance (lifting status) |
No Plate |
Weight of complete machine |
5100kg |
Product Details
Product features:
1. Power and Operation:This electric self propelled scissor lift is fully electrically driven-a green and eco-friendly solution that produces zero exhaust emissions, making it suitable for both indoor and outdoor operations.
2. Personnel and Load Capacity:The platform accommodates up to two people and boasts a maximum load capacity of 320 kg, ensuring stability and safety even when two individuals are working simultaneously, without any concerns regarding insufficient load-bearing capacity.
3. Stability and Gradeability: With a ground clearance of 0.3 meters and a robust structural design, the unit ensures exceptionally smooth and steady lifting operations, free from any swaying. Furthermore, it features excellent gradeability, allowing it to effortlessly navigate a wide variety of terrains and work environments.
4. Mobility and Deployment:Featuring a wheelbase of 2500 mm, this unit offers outstanding maneuverability. It is highly convenient for both transport and on-site use, allowing for rapid positioning and deployment at virtually any work location.
Product Application
Company Profile
Deliver,shipping and serving
FAQ
Q: What scenarios are scissor lifts suitable for?
A: Industrial field: factory equipment maintenance, production line operations, warehouse cargo storage and retrieval.
Construction: steel structure installation, exterior wall decoration, bridge maintenance.
Municipal maintenance: street light maintenance, landscaping, billboard installation.
Commercial places: shopping mall supermarket shelf arrangement, exhibition center stage construction.
Q: What is the maximum height and load of the scissor lift?
A: Maximum height: usually 6~20m.
Load capacity: generally between 200KG~500KG.
Q: Can the scissor lift be customized?
A: Yes.
Special size (extended/widened platform).
Additional functions (explosion-proof design, wireless remote control).
Brand LOGO or color matching.
Q: Does the scissor lift require regular maintenance?
A: Yes, regular maintenance includes:
Check the hydraulic oil, battery (electric type) or engine (diesel type).
Clean the track and lubricate the scissor joints.
Test safety devices (e.g. emergency brake, tilt alarm).
